Responsive Drag and Drop Grid Layout with jQuery

gridstack.js is a Responsive Drag and Drop Grid Layout with jQuery it’s a mobile-friendly modern typescript library for dashboard layout and creation. It helps to make a drag-and-drop, multi-column responsive dashboard easier that has never been so. Gridstack has many bindings and it works awesome with Knockout.js, React, Vue, Angular, Ember and others.

Basic Usage (jQuery Version):

  1. Include jQuery library and other required resources in the the document.
  • jQuery
  • jQuery UI
  • jQuery UI Touch Punch: for touch support (OPTIONAL)
  • gridstack.poly.js: for IE and older browsers (OPTIONAL)
<!-- Local -->
  <link href="/path/to/gridstack.css?x71615" rel="stylesheet" />
  <!-- Or From A CDN -->
  <link rel="stylesheet" href="https://cdn.jsdelivr.net/npm/[email protected]/dist/gridstack.min.css" />

Include the jQuery Gridstack.js plugin and other required resources at the end of the document.

<!-- Dependencies -->
  <script src="/path/to/cdn/jquery.min.js?x71615"></script>
  <script src="/path/to/cdn/jquery-ui.min.js?x71615"></script>
  <script src="/path/to/cdn/jquery.ui.touch-punch.min.js?x71615"></script>

  <!-- jQuery Gridstack.js -->
  <script src="gridstack.all.js"></script>
  <!-- Or from a CDN -->
  <script src="https://cdn.jsdelivr.net/npm/[email protected]/dist/gridstack.all.js"></script>
  <!-- Polyfill for old IE -->
  <script src="gridstack.poly.js"></script>

Create a sample draggable grid layout as follows.

<div class="grid-stack" data-gs-width="12">
    <div class="grid-stack-item" gs-x="0" data-gs-y="0" gs-width="4" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="4" data-gs-y="0" gs-width="4" gs-height="4">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="8" gs-y="0" gs-width="2" gs-height="2" gs-min-width="2" gs-no-resize="yes">
      <div class="grid-stack-item-content"> <span class="fa fa-hand-o-up"></span> Drag me! </div>
    </div>
    <div class="grid-stack-item" gs-x="10" gs-y="0" gs-width="2" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="0" gs-y="4" gs-width="2" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="2" gs-y="4" gs-width="2" gs-height="4">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="8" gs-y="4" gs-width="4" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="0" gs-y="6" gs-width="2" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="4" gs-y="6" gs-width="4" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="8" gs-y="6" gs-width="2" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
    <div class="grid-stack-item" gs-x="10" gs-y="6" gs-width="2" gs-height="2">
      <div class="grid-stack-item-content"></div>
    </div>
  </div>

Call the plugin and create a responsive & fluid 12 columns grid layout.

$(function () {
    $('.grid-stack').gridstack({
      column: 12
    });
  });

All possible options available.

$('.grid-stack').gridstack({

  // accept widgets dragged from other grids or from outside
  // true (uses '.grid-stack-item' class filter) or false
  // string for explicit class name
  // function (i: number, element: Element): boolean
  acceptWidgets: false,

  // turns animation on
  animate: false,

  // amount of columns
  column: 12,

  // max/min number of rows
  maxRow: 0,
  minRow: 0

  // maximum rows amount
  height: 0,

  // widget class
  itemClass: 'grid-stack-item',

  // class for placeholder
  placeholderClass: 'grid-stack-placeholder',

  // text for placeholder
  placeholderText: '',

  // draggable handle selector
  handle: '.grid-stack-item-content',

  // class for handle
  handleClass: null,

  // allow for selecting older behavior (adding STYLE element to HEAD element instead of parentNode)
  styleInHead: false,

  // one cell height
  cellHeight: 60,

  // gap size
  // e.g. '5px 10px 0 20px' or '5em 10em'
  margin: 10,

  // unit
  verticalMarginUnit: 'px',
  cellHeightUnit: 'px',

  // if false it tells to do not initialize existing items
  auto: true,

  // minimal width.
  minWidth: 768,

  // class set on grid when in one column mode
  oneColumnModeClass: 'grid-stack-one-column-mode',

  // set to true if you want oneColumnMode to use the DOM order and ignore x,y from normal multi column layouts during sorting. This enables you to have custom 1 column layout that differ from the rest.
  oneColumnModeDomSort: false,

  // enable floating widgets
  float: false,

  // makes grid static
  staticGrid: false,

  // if true the resizing handles are shown even the user is not hovering over the widget
  alwaysShowResizeHandle: false,

  // allows to owerride jQuery UI draggable options
  draggable: {handle: '.grid-stack-item-content', scroll: true, appendTo: 'body', containment: null},

  // let user drag nested grid items out of a parent or not
  dragOut: false,

  // allows to owerride jQuery UI resizable options
  resizable: {autoHide: true, handles: 'se'},

  // disallows dragging of widgets
  disableDrag: false

  // disallows resizing of widgets
  disableResize: false,

  // if `true` turns grid to RTL.
  // Possible values are `true`, `false`, `'auto'`
  rtl: 'auto',

  // if `true` widgets could be removed by dragging outside of the grid
  removable: false,

  // time in milliseconds before widget is being removed while dragging outside of the grid
  removeTimeout: 2000,

  // CSS class when in one column mode
  disableOneColumnMode: 'grid-stack-one-column-mode',

  // class that implement drag'n'drop functionallity for gridstack
  ddPlugin: null

});

API methods methods.

// Creates a new widget.
grid.addWidget(el, x, y, width, height, autoPosition, minWidth, maxWidth, minHeight, maxHeight, id);

// Initailizes batch updates.
// You will see no changes until commit method is called.
grid.batchUpdate();

// Relayout grid items to reclaim any empty space.
grid.compact();

// Gets current cell height.
grid.cellHeight();

// Update current cell height.
// grid.cell_height(grid.cell_width() * 1.2);
grid.cellHeight(val, noUpdate);

// Gets current cell width.
grid.cellWidth();

// Returns current vertical margin value.
grid.verticalMargin();

// value - new vertical margin value.
// noUpdate - if true, styles will not be updated.
grid.verticalMargin(value, noUpdate)

// Finishes batch updates. Updates DOM nodes. You must call it after batch_update.
grid.Commit();

// set/get floating widgets
grid.float(val);

// Disables / enables widgets moving/resizing.
grid.movable('.grid-stack-item', false);
grid.resizable('.grid-stack-item', true);

// Get the position of the cell under a pixel on screen.
// position - the position of the pixel to resolve in absolute coordinates, as an object with top and leftproperties
// useOffset - if true, value will be based on offset vs position (Optional. Default false). Useful when grid is within position: relative element
// Returns an object with properties x and y i.e. the column and row in the grid.
grid.getCellFromPixel(position, useOffset);

// Checks if specified area is empty.
grid.isAreaEmpty(x, y, width, height);

// Locks/unlocks widget.
// el - widget to modify.
// val - if true widget will be locked.
grid.locked(el, val);

// Make new widgets after new items are appended to the grid.
grid.makeWidget(el);

// Set the minWidth/maxWidth for a widget.
grid.minWidth(el, val);
grid.maxWidth(el, val);

// Set the minHeight/maxWidth for a widget.
grid.minHeight(el, val);
grid.maxHeight(el, val);

// Removes widget from the grid.
// detachNode - if false node won't be removed from the DOM
grid.removeWidget(el, detachNode);

// Removes all widgets from the grid.
// detachNode - if false node won't be removed from the DOM
grid.removeAll(detachNode);

// Changes widget size
grid.resize(el, width, height);

// Changes widget position
grid.move(el, x, y);

// Enables/Disables resizing.
grid.resizable(el, val);

// Enables/Disables moving.
grid.movable(el, val);

// Updates widget position/size.
grid.update(el, x, y, width, height);

// Returns true if the height of the grid will be less the vertical constraint. Always returns true if grid doesn't have height constraint.
grid.willItFit(x, y, width, height, autoPosition);

// Toggle the grid animation state.
// doAnimate - if true the grid will animate.
grid.setAnimation(doAnimate);

// Modify number of columns in the grid
// doNotPropagate - if true existing widgets will not be updated.
// NOTE: Use column() instead in v1.0+
grid.setColumn(column, doNotPropagate);

// Update widget position/size.
grid.setStatic(staticValue);

// Toggle the grid static state
// staticValue - if true the grid becomes static.
grid.update(el, x, y, width, height));

// Destroy the instance
// detachGrid - if false nodes and grid will not be removed from the DOM
grid.destroy([detachGrid]);

// Enables/disables the plugin
grid.enable();
grid.disable();

// Enables/disables widget moving. includeNewWidgets will force new widgets to be draggable as per doEnable's value by changing the disableDrag grid option.
grid.enableMove(doEnable, includeNewWidgets);

// Enables/disables widget resizing. includeNewWidgets will force new widgets to be resizable as per doEnable's value by changing the disableResize grid option.
grid.enableResize(doEnable, includeNewWidgets);

7. Event listeners available.

$('.grid-stack').on('added', function(event, items) {
  // after new items are added
});

$('.grid-stack').on('change', function(event, items) {
  // fired on change
});

$('.grid-stack').on('disable', function(event) {
  // var grid = event.target;
});

$('.grid-stack').on('dragstart', function(event, ui) {
  // var grid = this;
  // var element = event.target;
});

$('.grid-stack').on('dragstop',  function(event, ui) {
  // var grid = this;
  // var element = event.target;
});

$('.grid-stack').on('dropped',  function(event, previousWidget, newWidget) {
  // after dropped
});

$('.grid-stack').on('enable',  function(event) {
  // var grid = event.target;
});

$('.grid-stack').on('removed',  function(event, items) {
  // after removed
});

$('.grid-stack').on('resizestart',  function(event, ui) {
  // var grid = this;
  // var element = event.target;
});

$('.grid-stack').on('gsresizestop',  function(event, items) {
  // on stop resizing
});

File Information

File Size367.42 KB
Last Update12 Days Ago
Date Published2 Years Ago
LicenseMIT License
